ASTM/ASME SA516 Carbon Steel Plate for Pressure Vessels:

ASTM/ASME SA516 specification covers carbon steel plates produced mainly for application in welded pressure vessels where improved notch toughness is important. Tensile strength range is from 55 - 90 MPa and its versatility makes this specifications very popular in application.

ASME SA 516 GR70 Steel PlateASME SA 516 GR70 Steel Plate
ASME A516 GR.60 Steel SheetASME A516 GR.60 Steel Sheet

ASME SA516 grade introduction:
SA516 grade 55, SA516 grade 60, SA516 grade 65, SA516 grade 70. These 4 grades are mainly defined by their different tensile and yield strength range, which is influenced by content of Carbon. For example sa 516 grade 70 has the highest tensile and yield strength range due to the highest Carbon content(up to0.28%). For higher grade like sa516 gr-70 steel plate, preheating might be needed for metal arc welding process, especialy with thick steel plate.

Test&Inspection for ASME A516 Steel PlateTest&Inspection for ASME A516 Steel Plate

Delivery State:
SA516-70n reffers to normalized steel plate product, for steel plate and sheet thinner than 40mm we normally supply them as rolled-steel coil. Plates with thickness above 40mm  are supplied normalized. SA516 grade 70 steel plate density is 0.284 cu/in3 (7861 kg/m3).

Mild test:
ASME SA 516-carbon steel plates are manufactured with mill certification following EN10204 3.1 or EN10204 3.2 standard version.
Inspection: MOODY SGS BV GL DNV ABS LIOYD’S Test: X-ray, UT, magnetic particle, inspection.

ASME SA 516 GR.70-55 Chemical Composition:

Chemical Composition Maximum C % for thickness t (mm) Mn % for
thickness t (mm)
Si % P % max

S % max

6-12.5mm 12.5-25mm 25-50mm >50mm ≤12.5mm >12.5mm
ASME A516 Gr
55
0.18 0.20 0.22 0.25 0.55-0.98 0.60-1.30 0.13-0.45 0.035 0.035
ASME A516 Gr 60 0.21 0.23 0.23 0.25 0.6-0.9 0.80-1.20 0.13-0.45 0.035 0.035
ASME A516 Gr
65
0.24 0.26 0.26 0.28 0.85-1.20 0.85-1.20 0.13-0.45 0.035 0.035
ASME A516 Gr
70
0.27 0.28 0.28 0.30 0.85-1.20 0.85-1.20 0.13-0.45 0.035 0.035

ASME SA 516 GR.70-55 Mechanical Property:

Mechanical Property Tensile
strength
(MPa)
Minimum
yield
strength
(MPa)
Minimum elongation (%) gauge length
50mm 200mm
ASME A516 Gr
55
380-515 205 27 23
ASME A516 Gr 60 415 - 550 220 25 21
ASME A516 Gr
65
450 - 585 240 23 19
ASME A516 Gr
70
485 - 620 260 21 17

If you need more detailed info on ASME A516 Gr-70 of steel plate or boiler steel plate of other standard, don't hesitate to send a message now from our professional sales and expert team!
